RG11TMF Series 75 Ohm Tri-Shield Messenger Coaxial Cable Factory

RG11TMF Series 75 Ohm Coaxial Cable—Tri-Shield with Messenger, Jelly

Coaxial Cable can be used for the transmission of both analog and digital signals. It is adopted to television broadcasting, long-distance telephone transmission, short-distance connections between computer systems, and local area networks. It has the advantages of good temperature performance, ultraviolet resistance, flame retarded, good shielding performance and long service life.

Details & specifications

Construction
Technical Data Sheet
Documents to download

	Material	Diameter (mm)
Inner Conductor	CCS	1.63
Dielectric	Foamed PE	7.11
Al Foil	Bonded APA	7.32
Braiding	Al-Mg	7.80
Al Foil	APA	7.88
Messenger	Galvanized Steel	1.83
Jacket	PE With Jelly	10.16
Packaging	305m/Wooden reel	D455×d135×H325

lEAVE A MESSAGE

News

Build a professional-grade audio transmission system

In the pursuit of high-quality audio experience, the connection between professional audio equipment is crucia...
2024-05-30
Pigtails: The key connector within a fiber optic terminal box

In the optical fiber communication network, pigtail, as a key accessory, plays a decisive role in the optical ...
2024-05-23
RG6+ power cord, monitoring line and distribution line: build an efficient and stable monitoring system

In the digital age, surveillance systems have become an indispensable security guarantee in various fields. To...
2024-05-16
CAT5e S/FTP Lan cable: the stable and high-speed choice for LAN construction

In the digital age, LAN has become an indispensable part of our daily life and work. In order to meet the need...
2024-05-09

Product knowledge extension

The RG11TMF Series 75 Ohm Tri-Shield Messenger Coaxial Cable is a high-quality coaxial cable designed for use in a wide range of applications, including CATV, CCTV, and satellite TV. This cable features a tri-shield design with a messenger, providing excellent signal quality and interference protection. It also includes a jelly filling to protect against moisture and environmental damage.

Specifications:

75 Ohm impedance

Tri-shield with messenger

Jelly filling

Copper clad steel center conductor

Foam polyethylene dielectric

Aluminum foil shield with aluminum braid

PVC jacket

Nominal diameter: 0.405 inches

Nominal capacitance: 54 pF/ft

Velocity of propagation: 85%

Operating temperature range: -40°C to 60°C

Applications:

CATV

CCTV

Satellite TV

Capacitance	52 pF/m
Impedance	75 ± 3 ohms

SRL 5~1000MHz	≤-20 dB
Velocity	82%

MHz	dB/100ft	dB/100m.
55	0.96	3.15
211	1.90	6.23
250	2.05	6.72
270	2.13	7.00
300	2.25	7.38
330	2.35	7.71
350	2.42	7.94
400	2.60	8.53

MHz	dB/100ft	dB/100m.
450	2.75	9.02
500	2.90	9.51
550	3.04	9.97
600	3.18	10.43
750	3.65	11.97
870	4.06	13.31
1000	4.35	14.27
